Rix

Storm S6

Storm S6

Regular price $2,799.00 USD
Regular price Sale price $2,799.00 USD
Sale Sold out
Shipping calculated at checkout.



STORM S6 Thermal Imaging RifleScopes

CORE CHARACTERISTICS
Type: VOx Uncooled
Resolution, pixels: 640×512
Pixel Pitch, µm: 12
NETD, mK: <25
Frame Rate, Hz: 50

HIGH-PERFORMANCE SENSOR

The STORM has a 12um sensor boasting, NETD<25mK, and a 50Hz refresh rate, ensuring a clear and consistent view during observations. This series offers a total of four models for you to choose from: S1 (192x 144 pixels), S2 (256 x 192 pixels), S3(384x288 pixels), and S6(640x512 pixels).

RESOLUTION ENHANCED TECHNOLOGY (RET)

With our Resolution Enhanced Technology (RET), the S1, S2, and S3 models double the number of pixels and employ advanced Al algorithms to optimize the content displayed by these additional pixels. As a result, the picture quality is significantly improved, offering a clearer and more detailed image that enhances your outdoor observations and hunting experiences.

RET ON
RET OFF

1024×768 FULL COLOR OLED

The STORM’s OLED screen offers superior contrast and rich details, enhancing the hunting experience with a more immersive and detailed view.

REPLACEABLE BATTERY&QUICK-DETACH DESIGN

The STORM series is powered by a replaceable 18650 battery that enables the S1, S2, and S3 models to operate continuously for up to 6 hours, while the S6 model offers 5 hours of uninterrupted use. The innovative 90-degree, quick-detach battery cap design facilitates effortless battery swapping, ensuring minimal downtime during your hunting adventures.

INTUITIVE OPERATING SYSTEM

We have developed a unique intuitive operating system for STORM, where each function corresponds to a single button. You no longer need to scroll through menus to find the desired function. The device's buttons are directly mapped to the user interface (UI), so when you press a button, the corresponding function on the UI lights up, providing a clear indication of which function you have triggered. Additionally, these four buttons can also be used as directional keys, allowing for convenient zeroing.



RETURN TO CENTER FUNCTION (RTC)

After zeroing, the RTC function will automatically reposition the reticle closer to the center of the x-axis and y-axis. If the deviation from the center position is minimal, it can even realign the reticle directly to the center. enabling you to have a more comfortable field of view and making it easier to maintain focus on the target.

ADJUSTABLE
PICTURE-IN-PICTURE (PIP)

Unlike other scopes where the Picture-in-Picture (PIP) image is simply magnified along with the outer image, the STORM allows you to adjust the magnification level of the PIP image independently, enabling users to maintain awareness of the surroundings and improve shooting accuracy using the PIP function.



LIGHTWEIGHT AND COMPACT DESIGN

The STORM features a compact and lightweight design, weighting around 440g, making it suitable for handheld use. It also includes a quick-detach Picatinny mount for easy installation. The aluminum alloy construction ensures durability and high-quality performance.



MORE FEATURES

Powerful Base Magnification

With a base magnification of 3.5x, the S1, S2, and S3models provide powerful, improved clarity when observing distant targets. This allows for more precise long-distance hunting, even when utilizing digital zoom.

Weather Mode

Through intelligent parameter adjustments, our product guarantees a consistently sharp and detailed view, regardless of the weather conditions. No longer will rainy days or foggy nights obstruct your vision. Overcome nature's challenges and enjoy clear visibility at all times.

1000g Impact Resistance

The STORM is built to withstand impacts of up to 1000g, making it an excellent choice for hunting weapons with larger calibers such as .375 H&H, 12-gauge, and 9.3x64. Its durable design ensures long-term reliability and remains undamaged even in the most challenging conditions.

IP67 Waterproof

Engineered with an impressive IP67 waterproof, the STORM is fortified against water intrusion, ensuring robust protection for the device. This exceptional waterproofing capability safeguards the internal components, significantly extending its lifespan.

Photo, Video Recording and Built-in MIC

The STORM offers photo and video recording capabilities, ensuring effortless capture of remarkable moments day or night. Experience uncompromising audio quality with our carefully selected built-in microphone.

A Wide Array of Reticle Choices

The STORM presents an extensive selection of reticle options, catering to your specific preferences and shooting requirements. With four distinct reticle colors and eight unique reticle styles, you have a grand total of 32 reticle combinations at your disposal.

Wi-Fi integration with RIX+ APP

The STORM has built-in Wi-Fi, enabling seamless connectivity with your Android or iOS smartphone through the RIX+ app. This powerful combination provides numerous advantages, such as wireless software updates and live image streaming to your mobile device screen.

RAV Function

With its cutting-edge Recoil Activated Video feature, the STORM effortlessly captures exhilarating moments, even if you forget to manually start recording. Equipped to detect recoil, it automatically records the moments before and after each shot.

Sensor Specifications
Type VOx Uncooled
Resolution, 640×512 pixels
Pixel Pitch, 12µm
NETD, <25 mK
Frame Rate, 50 Hz
Optical Specifications
Objective Lens,35mm
Optic Zoom, x2
Field of View, @ 100 yd 12.5°/21.9yd
Digital Zoom, 1 to 4x
Eye Relief, 48 mm
Diopter Adjustment, -5 to +5 D
Detection Range, 1800/1969 m/yd
Display Specifications
Type OLED
Resolution, 1024×768 pixels
Wi-Fi
Wireless Protocol Wi-Fi
Frequency, 2.4GHz
Video Recorder
Video / Photo Resolution, 1024×768 pixels
Video / Photo Format .mp4 / .jpg
Built-in Memory, 32 GB
Physical Specifications
Degree of Protection, IP67
Operating Temperature Range, -4 to 122 °F
Weight, 0.97 lb
Dimensions, 5.3×2.5×2.2 inches
Connections and Compatibilities
Battery Type 18650
Capacity, 3200 mAh
Operating Time on Battery Pack (at t=72°F), 5 hr
External Power Supply, 5V (Type C USB)
Max Recoil Power on Rifled Weapon (Eo), 1000g/6000Joules
Compatible Mounts
Picatinny mount
