Rearden

R2S (HT)

R2S (HT)

Regular price $67.50 USD
Regular price Sale price $67.50 USD
Sale Sold out
Shipping calculated at checkout.
Thread
Shoulder
  • 17-4 PH
  • Atlas and Atlas XL compatible
  • Plan B compatible
  • H900 Wheat Finish (Variations exist)
  • Shims not included, if you would like to specifically time this, shims will be required.
  • Note: your barrel may require a shim if the manufacturer did not put a thread relief on it.

Weight and Length

Thread Pitch Weight Length Length Added
1/2-28 2.05 oz 1.74″ 1.115″
1/2-28 Tapered 2.0 oz 1.74″ 0.9275″
5/8-24 Tapered 1.75 oz 1.74″ 0.9275″
5/8-24 1.6 oz 1.74″ 1.115″
14×1 LH 2.01 oz 1.74″ 1.215″
13.5×1 LH 1.8 oz 1.74″ 0.99″

These fit Plan B type mounts. Always use an alignment rod to ensure that the entire system is set up correctly. Make sure all surfaces are cleaned and the muzzle device has been torqued and Rockset to the barrel. Use on a Q can voids your warranty, be warned.

Torque the muzzle device to approximately 30 ft lbs. Make sure the muzzle device is square against the shoulder. When setting the silencer on the muzzle device, ensure that the threads and tapers are clean. Torque the suppressor to 10 ft lbs. Ensure alignment. Enjoy.
